Electronic thermal conductive potting silicone

Product No:HY-2 HY-90 HY-93 series
Brand:HONG YE JIE
Product Usage:Electronic thermal conductive potting silicone is a kind of two components (1:1mixing ratio) addition cure silicone with the Characteristics of heat-conducting low viscosity Inherent flame resistance waterproofing etc. It can cure both at room temperature and heated temperature and the curing time can be accelerated by higher temperature.

ELECTRONIC THERMAL CONDUCTIVE POTTING SILICONE DESCRIPTION
        Electronic thermal conductive potting silicone is a kind of two components (1:1mixing ratio) addition cure silicone with the Characteristics of heat-conducting, low viscosity, Inherent flame resistance, waterproofing, etc. It can cure both at room temperature and heated temperature and the curing time can be accelerated by higher temperature.



ELECTRONIC THERMAL CONDUCTIVE POTTING SILICONE APPLICATION
• Applying for the surface of PC (Poly-carbonate), PP, ABS, PVC, Metal, etc.

• High powered electronic encapsulation and DC/DC module and circuit board which requires heat dissipation and high temperature resistance.

• Insulation, waterproof and bonding of general electronic components.

• Filling for LED, LCD electronic display, circuit board, PCB substrate, etc.

• Outdoor protection for LED screen.



ELECTRONIC THERMAL CONDUCTIVE POTTING SILICONE NOTES AND OPERATION INSTRUCTIONS
1) The following material may hinder the curing of electronic potting silicone, so please use after the test. When necessary, please clean the application areas.
- Organotin compound or Condensation silicone with organotin
- Sulphur, sulfide and sulfur rubber materials.
- Amine compounds as well as contains the amine materials.
 - Pewters solder flux

2) Deaeration the mixture in vacuum pump under 0.08 MPa for 3-5 minutes.Then the mixture could be used for pouring.

3) Please note that the thickness of the silicone affects the curing time. If the silicone used is a little thick, then the curing time will be a little longer. The temperature also affects the curing time. When in lower temperature, we suggest customers appropriately heat the mixture to accelerate vulcanization.

4) Above electronic potting silicone should be sealed storage. The mixture should be used up to avoid causing waste.

5) Above silicone belongs to non-dangerous goods, but keep away from mouth and eyes.
6) When it gets stratified after a period of storage, please mix it evenly before using, this does not affect the performance.


ELECTRONIC THERMAL CONDUCTIVE POTTING SILICONE PACKAGING
Standard packing for RTV-2 addition cure electronic potting silicone is 22kg/set (Part A 20kg + Part B 2kg)



ELECTRONIC THERMAL CONDUCTIVE POTTING SILICONE SHELF LIFE AND TRANSPORTATION
1. Twelve(12) months from date of shipment when stored at 24C in original unopened packages.

2. This kind of product is non-dangerous product, it can be transported as general chemicals.

3. Products exceed the storage life should be confirmed normal before using.
